| Specification | Details |
|---|---|
| System Capacity | 200 Gallons Per Day (GPD) |
| Permeate Flow | 0.13 GPM |
| Operating Pressure | 165 PSI |
| Rejection Rate | 95% – 99% |
| Typical Recovery | 50% |
| Connection Size | Inlet / Product / Reject – 3/8″ |
| Filtration Stages | Stage 1: 5 Micron PP Sediment Filter (20″ × 2.5″)Stage 2: GAC Carbon Filter (20″ × 2.5″)Stage 3: CTO Carbon Filter (20″ × 2.5″)Stage 4: RO Membrane – 100 GPD × 2 (10″ × 2.5″)Stage 5: Post Carbon Filter |
| Pre-Filter Housing | 20″ × 2.5″ (Qty: 3) |
| Pump | 24 V DC (Qty: 2) |
| Motor Flow Rate | 2.4 LPM |
| Power Supply | 110–220 V AC / 24 V DC |
| Safety Protection | High & Low Pressure Switch |
| System Dimensions (H×W×D) | 35″ × 17″ × 14″ |
| Approximate Weight | 19 kg (42 lbs) |
