The Aqua Care Pressure Gauge Y Type is designed for accurate and reliable pressure monitoring in water treatment systems, pumps, plumbing installations, and industrial applications. Featuring an analog Bourdon tube measuring mechanism and a clear dual-scale dial displaying pressure in bar and PSI, it enables convenient pressure readings across a range of operating conditions.
Original price was: 100 د.إ.60 د.إCurrent price is: 60 د.إ.
Shipping calculated at checkout.
|
Specification |
Details |
|---|---|
|
Product Name |
Pressure Gauge Y Type |
|
Brand |
Aqua Care |
|
Measuring Principle |
Bourdon Tube |
|
Dial Size |
Approximately 63 mm (2.5 inches) |
|
Accuracy Class |
±1.6% of full scale |
|
Case Material |
Stainless Steel |
|
Lens Material |
Acrylic |
|
Connection Type |
Bottom Entry |
|
Thread Size |
1/4″ BSP / NPT |
|
Wetted Parts |
Brass |
|
Operating Temperature |
-10°C to +60°C |
|
Pressure Display |
Bar and PSI |
|
Available Pressure Ranges |
0–10 bar, 0–16 bar, 0–25 bar, 0–40 bar, 0–60 bar |
|
Equivalent PSI Ranges |
0–150 PSI, 0–230 PSI, 0–360 PSI, 0–600 PSI, 0–900 PSI |
