The Hydranautics SWC5 MAX is a spiral-wound seawater reverse osmosis membrane element designed for desalination applications. It features a composite polyamide membrane with an active area of 440 ft² (40.9 m²), delivering a specified permeate flow rate of 9,900 GPD (37.5 m³/day) and a salt rejection rate of 99.8% under the manufacturer’s standard test conditions.
Shipping calculated at checkout.
| Specification | Details |
|---|---|
| Brand | Hydranautics |
| Model | SWC5 MAX |
| Product Type | Seawater RO Membrane Element |
| Configuration | Spiral Wound |
| Membrane Polymer | Composite Polyamide |
| Active Membrane Area | 440 ft² (40.9 m²) |
| Specified Permeate Flow Rate | 9,900 GPD (37.5 m³/day) |
| Salt Rejection | 99.8% |
| Minimum Salt Rejection | 99.7% |
| Element Length | 40 inches (1,016 mm) |
| Element Diameter | 7.89 inches (200 mm) |
| Inner Diameter | 1.125 inches (28.6 mm) |
| Maximum Applied Pressure | 1,200 PSI (8.27 MPa) |
| Maximum Operating Temperature | 45°C (113°F) |
| Maximum Chlorine Concentration | Less than 0.1 ppm |
| Continuous Operating pH Range | 2–11 |
| Cleaning pH Range | 1–13 |
| Maximum Feedwater Turbidity | 1.0 NTU |
| Maximum Feedwater SDI (15 min) | 5.0 |
| Maximum Feed Flow | 75 GPM (17.0 m³/h) |
| Minimum Brine Flow | 12 GPM (2.7 m³/h) |
| Maximum Pressure Drop per Element | 15 PSI (0.10 MPa) |
| Packaging | Sealed polyethylene bag with sodium metabisulfite solution, then cardboard box |
| Included Accessories | Brine seal, interconnector, O-rings |
